Hayward H150FD User Manual

Pomona, CA Clemmons, NC Nashville, TN
Tel: 908-351-5400 www.haywardpool.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
3
Basicsafetyprecautionsshouldalwaysbefollowed,includingthefollowing:Failuretofollowinstructions
cancausesevereinjuryand/ordeath.
Thisisthesafety-alertsymbol.Whenyouseethissymbolonyourequipmentorinthismanual,lookfor
oneofthefollowingsignalwordsandbealerttothepotentialforpersonalinjury.
WARNINGwarnsabouthazardsthatcouldcauseseriouspersonalinjury,deathormajorpropertydam-
ageandifignoredpresentsapotentialhazard.
CAUTIONwarnsabouthazardsthatwillorcancauseminorormoderatepersonalinjuryand/orprop-
ertydamageandifignoredpresentsapotentialhazard.Itcanalsomakeconsumersawareofactionsthat
areunpredictableandunsafe.
ATTENTIONindicatesspecialinstructionsthatareimportantbutnotrelatedtohazards.
READ AND FOLLOW ALL INSTRUCTIONS IN THIS OWNER’S
MANUAL AND ON EQUIPMENT.
IMPORTANT SAFETY INSTRUCTIONS
Before installing or servicing this electrical equipment, turn power supply OFF.
KEEP SAFETY LABELS IN GOOD CONDITION AND REPLACE IF MISSING OR DAMAGED.
WARNING–Toreduceriskofinjury,donotpermitchildrentouseorclimbontheheater,pumpsor
lters.Closelysupervisechildrenatalltimes.Componentssuchastheltrationsystem,pumps,and
heatersmustbepositionedtopreventchildrenfromusingthemasameansofaccesstothepool.
CAUTION –Thisheaterisintendedforuseonpermanentlyinstalledswimmingpoolsandmayalso
beusedwithspas.DoNOTusewithstorablepools.Apermanentlyinstalledpoolisconstructedinor
onthegroundorinabuildingsuchthatitcannotbereadilydisassembledforstorage.Astorablepoolis
constructedsothatitiscapableofbeingreadilydisassembledforstorageandreassembledtoitsoriginal
integrity.
Thoughthisproductisdesignedforoutdooruse,itisstronglyrecommendedtoprotecttheelectrical
componentsfromtheweather.Selectawelldrainedarea,onethatwillnotoodwhenitrains.Itrequiresfree
circulationofairforcooling.Donotinstallinadampornon-ventilatedlocation.
WARNING –Itisrequiredthatlicensedelectriciansdoallelectricalwiring.Riskof
ElectricShock.Hazardousvoltagecanshock,burn,causedeathorseriousproperty
damage.Toreducetheriskofelectricshock,doNOTuseanextensioncordtoconnect
unittoelectricsupply.Provideaproperlylocatedoutlet.AllelectricalwiringMUSTbe
inconformancewithapplicablelocalandnationalcodesandregulations.Beforework-
ingonthisunit,turnoffpowersupplytotheheater.
WARNING –Toreducetheriskofelectricshockreplacedamagedwiringimmediately.Locateconduit
topreventabusefromlawnmowers,hedgetrimmersandotherequipment.
WARNING –Failuretobondtopoolstructurewillincreaseriskforelectrocutionandcouldresultin
injuryordeath.Toreducetheriskofelectricshock,theelectricianmustcomplywithinstallationin-
structionsandmustbondtheheateraccordingly.Inaddition,thelicensedelectricianmustalsoconform
tolocalelectricalcodesforbondingrequirements.
SAFETY INFORMATION

Hayward H150FD Specifications

General

Heating Capacity	150, 000 BTU/hr
Fuel Type	Natural Gas or Propane
Heat Exchanger Material	Cupro Nickel
Ignition Type	Electronic Ignition
Type	Forced Draft Heater
Efficiency	82%
Warranty	1 Year
