29
SECTION 6. QUALIFIED TECHNICIAN - MAINTENANCE/SERVICING
Figure 47: Burner Removal
Figure 48: Pilot Assembly Removal
GAS VALVE
SECURING SCREW
CLICKLITE
TM
SHOWN WITHOUT SURROUNDING
HEATER CABINET FOR CLARITY
SECURING SCREW
PILOT
2 SCREWS
BRACKET
CLICKLITE
TM
CLINCH
STUD
