18
Lift straight up to remove blower assembly from
the burner. Gently lay the blower aside.
Remove blower assembly
Step 11
Remove blower/burner assembly
Slide left slightly and then lift the blower / burner
assembly straight up out of the heater.
Remove the 4 each 7/16” nuts that hold the blower
assembly to the burner.
Remove blower nuts
This is showing you a clean burner rear and front
view.
Clean burner
Step 9
Step 12
Step 10
Clean/Replace Burner (cont.)
