Hayward HP55TR - Specifications and Dimensions; Performance Data

2. SPECIFICATIONS
2.1 Performance Data of Swimming Pool Heat Pump Unit
*** REFRIGERANT: R410A
Unit Model HP55TR HP70TR
Heating Capacity
kW 16.2 20.6
BTU/h 55,000 70,000
Heating Power Input kW 2.6 4.2
Running Current A 11.8 18.96
Power Supply V/Hz 208-230V~/60Hz 208-230V~/60Hz
Compressor Quantity 1 1
Compressor(s) Rotary Rotary
Fan Quantity 1 1
Fan Power Input W 120 120
Fan Rotate Speed RPM 850 850
Fan Direction Horizontal Horizontal
Noise (at 1 meter) dB(A) 54 56
Water Connection inch 1.5 1.5
Water Flow Volume Imperial/US m
3
/h 4.5 6
Water Pressure Drop (max) kPa 10 12
Unit Net Dimensions (L/W/H) mm 1025/430/660 1140/430/875
Heating: Ambient temp (DB/WB): 24
º
C / 19
º
C
Water temp (in/out): 26
º
C / 28
º
C
2
