To Set Turbo Cell Type
Before operation, the SwimPure Plus must be configured for the chlorinator cell that will be used.
Your model SwimPure Plus has been packaged with a corresponding Turbo cell. Refer to the fol-
lowing information and steps below to set the Turbo cell type.
"t-3" = if using a T-CELL-3, GLX-CELL-3-W Turbo Cell
"t-9 = for all SWP9 models or if using a T-CELL-9, GLX-CELL-9-W Turbo Cell
"t-15" = for all SWP15 models or if using a T-CELL-15, GLX-CELL-15-W Turbo Cell
"t-5" = if using a GLX-CELL-5, GLX-CELL-5-W Turbo Cell
1. Slide the Main Switch to the "Auto" position.
2. Push the Diagnostic button repeatedly until "t-xx" appears on the display ("t-15" is the factory
default). If the desired cell type is displayed skip to step 4.
3. To change to a different cell type, slide the Main Switch from "Auto" to "Super Chlorinate" and
back to "Auto". Repeat this process until the desired cell type is displayed.
4. Push the Diagnostic button to exit.
Desired Output %" adjustment knob
The "Desired Output %" adjustment knob is located in the lower center of the SwimPure Plus control
panel. This setting is used to control the amount of chlorine the SwimPure Plus generates. Raise
this setting to increase chlorine level and lower it to decrease chlorine level. Note: The "Desired
Output %" adjustment will not function when the SwimPure Plus is being controlled by a remote
pool automation control.
Salt Display
Refer to the Water Chemistry section for recommended salt levels as well as how to add/remove
salt. The Salt Display shows the average salt level of the pool water. The factory default display
is in English units (ppm). If Metric units (grams per liter) are preferred, follow the procedure under
Temperature Display.
Temperature Display
The Temperature Display shows the current temperature of the pool water. The factory default
display is in ºF. Both the Temperature Display and the Salt Display can be programmed to display
in Metric units. To display temperature in ºC and salt level in g/l, perform the following steps:
1. Slide the Main Switch to the "Auto" position.
2. Push the Diagnostic button repeatedly until "ºF" appears on the display.
3. Slide the Main Switch from "Auto" to "Super Chlorinate" and back to "Auto".
4. Push the Diagnostic button to exit.
Instant Salinity
The Instant Salinity display is the measured salt level of the pool water at that moment. If salt has
recently been added, the Instant Salinity may show the change while the Salt Display (average salt
level) may take some time before the changes can be seen. Under these circumstances, you may
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
8
