Radio System
6 Technical Data
General Technical Data
System micron 4
Max. number of control commands 24, digital and STOP
Unique system addresses over 65,000 combinations
Transmitter-specific Technical Data
Transmitting power: FuS 671/3 < 10 mW ( synthesizer )
Transmitter antenna internal
Battery type FuB 3A ( blue , NiCd )
Power supply with NiCd battery 6V DC / 250 mAh
Battery charge at 50 % duty cycle
at 100 % duty cycle
8 hours
4 hours
Operating temperature range –25 °C to 75 °C ( –13 °F to +167 °F )
Housing material ABS plastic with shock protection
Housing color orange
Dimensions 236 x 87 x 65 mm ( 9.3 x 3.4 x 2.6 " )
Weight approx. 500 g ( 1.0 lb. )
System of protection IP 55 ( Nema 4 )
Accessories
The following accessories are available for the transmitter micron 4 and must be ordered
separately :
Description Order No.
Belt clip for micron transmitter ( standard accessory ) D-500006
NiCd battery FuB 3A, blue, 6V / 250 mAh FuB 3A
Adapter for FuB 3A batteries ( for battery charger ) D-900064
Battery charger FLG 105 ( indicate distribution voltage range ! ) FLG 105
Transmitter labels micron 4, sheet 1 [ 31.397 ] G-900212
Transmitter labels micron 4, sheet 2 [ 31.398 ] G-900213
Transmitter labels micron 4, sheet 3 [ 31.399 ] G-900214
