Vedpak 202_Version 1_05.2015
GB
Monitor
I. Appearance and Dimension (unit: mm)
II. Technical Parameters
Display Device Color TFT-LCD
Interface Digital TTL
Resolution 800×(RGB)×480
Active Area (mm) 153.60×86.64
View Angle (LR/UD) L/R: 70/70 U/D: 50/70
Contrast Ratio 500:1
Luminance (nits) 400
Response Time (ms) 25
Load Dump DC 12+87V/Td=400ms
Operating Temperature -20
o
C ~ +60
o
C
Storage Temperature -30
o
C ~ +80
o
C
Application Power Supply DC11V ~ 32V (5W Max)
Audio Output ≤1W
1. Power
2. Left (Volume-)
3. Right (Volume+)
4. Menu
5. Down
6. Up
7. CAM Switch
Color TFT-LCD Monitor
Sunshade
Bracket Screw
Bracket
Power Indicator
Red: Stand-by
