User's Guide
Knowing the Parts
2-11
replaced as a single unit through HCL authorized dealer.
2. Battery Lock Latch
Push the latch to the lock side to lock and secure the battery, or push the latch to the unlock side for
unpacking the battery pack.
3. Battery Release Latch
To release the battery, first locate the Battery Lock Latch at the left side with unlock status, then push the
Battery Release Latch to the right end to remove the battery pack.
4. Rating Label
The label shows the model number and other information about your notebook.
5. Hard Disk Compartment Cover
This is where the hard disk drive is located. The hard disk drive stores all the system data. The hard disk
drive can be upgraded to a larger capacity. Visit an HCL authorized service center for information on Hard
Disk upgrades for your Notebook PC.
Warning :
End-user removal of the hard disk drive will void the warranty.
6. Fan Outlet /Air vent
