Operating Instructions
4
R
e
m
o
t
e
De
s
c
r
i
p
t
i
o
n
Button “5” for PIP fuction (picture in picture)①
N
o
t
e:
Press button "5" you can see picture in picture on TV.
3) Power up all units, the switch, sources and displays.
Please refer to Connection Diagram 2.
C
o
n
n
e
c
t
i
n
g
a
n
d
o
p
e
r
a
t
in
g
1) Connect the HDMI input sources into HDMI switch
2) Connect the HDMI switch with the display.
Connection Diagram 1 (Support 4Kx2K)
PC
HDMI Out
STB XBOX Blu-ray
HDMI In
CEC pass through
4K TV
To Next Page
