Healthy Climate Solutions ERV5-150-TPD User Manual (English)

Questions and Answers:

A
amandamilesAug 12, 2025
Why is there poor airflow from my Healthy Climate Solutions ERV5-150-TPD?
- M
  marcus83Aug 12, 2025
  Poor airflow from your Healthy Climate Solutions Fan can stem from several issues. Check for the following: * Blocked mesh on outside hoods or plugged filters. * An obstructed core or closed/blocked house grilles. * Closed dampers, a poor power supply, or ductwork restrictions. * An improper speed control setting or an improperly balanced ERV/HRV airflow. To resolve this, clean exterior hoods or vents, clean or replace the filter and core (every 3 months if it is MERV 13). Ensure grilles are open, adjust dampers, have an electrician check the power supply, inspect duct installation, increase the ERV/HRV speed, and have a contractor balance the ERV/HRV.
K
Kristen KellyAug 19, 2025
Why does the supply air from my Healthy Climate Solutions ERV5-150-TPD Fan feel cold?
- Y
  ygrossAug 19, 2025
  The supply air from your Healthy Climate Solutions Fan might feel cold due to: poor location of supply grilles, airflow irritating occupants or extremely cold outdoor temperatures. To solve this, locate the grilles high on the walls or under the baseboards, install ceiling mounted diffuser or grilles so as not to direct airflow onto occupants and turn down the ERV/HRV supply speed. A small duct heater (1kW) could be used to temper the supply air. Consider rearranging furniture or opening closed doors that restrict air movement. If supply air is ducted into furnace return, the furnace fan may need to run continuously to distribute ventilation air comfortably.
D
David HooverAug 23, 2025
What to do if my Healthy Climate Solutions ERV5-150-TPD Fan dehumidistat is not operating?
- E
  edominguezAug 25, 2025
  If the dehumidistat on your Healthy Climate Solutions Fan is not operating, it could be due to a few reasons: the outdoor temperature may be above 59ºF (15ºC), there might be an improper low-voltage connection, an external low voltage short caused by a staple or nail, or the dehumidistat might be set to OFF. Check that the correct terminals have been used and examine external wiring for shorts. Set the dehumidistat at the desired level. Note that the dehumidistat functions normally when the outdoor temperature is above 59ºF (15ºC).
K
Kathleen SmithAug 27, 2025
Why are my Healthy Climate Solutions HRV units or ducts frosting up?
- J
  Jerry HillAug 27, 2025
  HRV units and/or ducts frosting up in your Healthy Climate Solutions system can be caused by improperly balanced HRV air flows or a malfunction of the HRV defrost system. To address this, have an HVAC contractor balance the HRV airflows and ensure the damper defrost is operating during the self-test.
M
Michael HooperAug 31, 2025
What causes condensation or ice build-up in the insulated duct to the outside of my Healthy Climate Solutions ERV5-150-TPD?
- K
  Kimberly LewisAug 31, 2025
  Condensation or ice build-up in the insulated duct to the outside of your Healthy Climate Solutions Fan can be due to an incomplete vapor barrier around the insulated duct or a hole/tear in the outer duct covering. To fix this, tape and seal all joints and tape any holes or tears in the outer duct covering. Ensure that the vapor barrier is completely sealed.
L
Leah WilliamsSep 3, 2025
Why are humidity levels too low with my Healthy Climate Solutions Fan?
- J
  Justin RodriguezSep 3, 2025
  Low humidity levels with your Healthy Climate Solutions Fan can occur if the dehumidistat control is set too low, the blower speed of the ERV/HRV is too high, or the ERV/HRV airflows are improperly balanced. To resolve this, set the dehumidistat at a higher level and decrease the ERV/HRV blower speed. You may need to add humidity through the use of humidifiers. Consider having a contractor balance the ERV/HRV airflows.
B
Brandon BrewerSep 7, 2025
Why is there water in the bottom of my Healthy Climate Solutions ERV/HRV unit?
- D
  Daniel JuarezSep 7, 2025
  Water accumulation at the bottom of your Healthy Climate Solutions ERV/HRV unit can be attributed to a few potential causes: plugged drain pans, improper connection of ERV/HRV drain lines, the unit not being level, obstructed drain lines, or the heat exchange core not being properly installed. Ensure the o-ring on the drain nozzle sits properly, check the drain line for kinks, inspect water drain connections, and make sure water drains properly from pan(s).

Healthy Climate Solutions ERV5-150-TPD Specifications

General

Type	Energy Recovery Ventilator
Airflow Capacity	150 CFM
Airflow @ 0.2 in. w.g.	150 CFM
Frequency	60 Hz
Weight	28 lbs
Voltage	120V

Summary

General Information and Cross-References

Safety and Important Notes

Critical safety precautions and essential operational notes for safe installation and use.

Model and Catalog Number Cross-References

Table listing model numbers and their corresponding Lennox catalog numbers for easy reference.

Technical Definitions and Application Guidance

Terms and Definitions

Glossary of terms used throughout the manual, explaining technical language and concepts.

Application Guidance

Describes when to use ERV vs. HRV units and provides general application context.

Required Tools and Materials

Unit Specifications

Unit Specifications (Continued)

Optional Fan Curve Speeds

Unit Dimensions and Diagrams

Ducting, Defrost, and Operational Modes

Ducting for Oval Ports

Instructions on shaping ductwork to fit the unit's oval ports for efficient airflow.

Defrost Cycle Operation

Explains how the unit manages defrost cycles in cold weather conditions for optimal performance.

Ventilation Operational Modes

Describes the different operating modes available for the ERV/HRV units to manage indoor air quality.

Ventilation Rate and Control Mode Selection

Determining Ventilation Needs

Guidance on calculating the appropriate ventilation rate based on home characteristics and occupancy.

Operational Modes Overview

A summary of available ventilation operational modes and their intended use cases.

iComfort Smart Thermostat Integration

iComfort Control Features

Outlines the features and benefits of using iComfort E30 or S30 thermostats to control the ERV/HRV.

iComfort Installation Overview

Provides an overview of the installation process and wiring considerations for iComfort controls.

ERV/HRV Wiring Diagrams

iComfort Wiring Connections

Detailed wiring diagrams for connecting the ERV/HRV to iComfort E30 and S30 systems.

Thermostat Ventilation Parameter Configuration

Timed Ventilation Control Parameters

Configuration settings for the timed ventilation mode, including rate and limits.

ASHRAE Ventilation Control Parameters

Configuration settings for ASHRAE compliant ventilation mode, including rate and limits.

Ventilation Control Mode Details

Timed Mode Operation and ASHRAE Standard

Explains the functionality of timed mode and the basis of ASHRAE 62.2 standards for ventilation.

Smart Hub Ventilation Parameter Settings

Timed Mode Smart Hub Parameters

Specific parameters for timed ventilation control via the Smart Hub, covering minutes, rates, and temperature limits.

ASHRAE Mode Smart Hub Parameters

Specific parameters for ASHRAE compliant ventilation via the Smart Hub, covering rates and conditions.

iComfort User Guide and Dehumidistat Function

Ventilation Home Screen and Settings

Explains how to view ventilation status on the iComfort screen and navigate the settings menu.

Dehumidistat Operation Explained

Details how the built-in dehumidistat functions to manage indoor humidity levels.

Ventilation Control Options

Push Button Ventilation Control (Y8249)

Describes the features and operation of the basic H/C ERV/HRV Ventilation Push Button Control.

Deluxe Ventilation Control (Y8250)

Details the advanced features and operation of the H/C ERV/HRV Deluxe Ventilation Control.

Timer Controls and Their Operation

20/40/60 Minute Timer (Y2169) Operation

Instructions for installing and operating the optional wired 20/40/60 Minute Timer.

Wireless Timer (Y8251) Operation

Instructions for operating the optional H/C Ventilation Wireless Timer, including pairing.

Wireless Timer Range Extension and Installation Methods Overview

Wireless Repeater (Y8252) Installation and Pairing

Guide to installing and pairing wireless repeaters to extend the range of wireless timers.

Installation Methods Overview

Introduces the three primary installation methods for ERV/HRV units.

Ductwork Sizing and Installation

Guidelines for proper ductwork sizing and installation to ensure optimal system performance.

Installation Method: Simplified (Return/Return)

Key Points for Simplified Installation

Highlights critical considerations for the simplified (Return/Return) installation method.

Installation Method: Partially Dedicated

Key Points for Partially Dedicated Installation

Highlights critical considerations for the partially dedicated installation method.

Installation Method: Fully Dedicated

Key Points for Fully Dedicated Installation

Highlights critical considerations for the fully dedicated installation method.

Unit Installation Location and Mounting

Recommended Installation Location

Provides recommendations for choosing an optimal location for the ERV/HRV unit.

Suspending the Unit

Detailed steps for properly suspending the unit using hanging straps for vibration isolation.

Specific Model Installation and Drain Connections

Installing the ERV5-130 Mounting Bracket

Instructions for attaching the mounting bracket to the ERV5-130 unit.

Installing the Condensate Drain Connection

Crucial steps for correctly installing the drain connection to manage condensate.

Installing Optional Plugs (ERV5-150/175-TPD)

Guide for installing optional plugs on specific ERV5-TPD models.

Air Distribution Components and Weatherhoods

Installing Grilles and Diffusers

Instructions for installing grilles and diffusers to balance airflow within rooms.

Weatherhood Installation Requirements

Guidelines for correctly installing intake and exhaust weatherhoods to protect the unit.

Weatherhoods and Dual Hood Kit Details

Fixed Covered Weatherhoods

Information on fixed covered weatherhoods, including sizes and catalog numbers.

Dual Hood Kit (Y3813) Installation

Details on installing the H/C ERV/HRV Dual Hood Kit for simplified wall connections.

Airflow Performance Charts and Control Installation

Intake Airflow Charts

Charts showing airflow performance for intake, helpful for system balancing.

Installing Ventilation Controls

Step-by-step guide for installing various ventilation controls onto walls or electrical boxes.

Ventilation Control Installation and Operation

Wireless Timer Pairing and Installation

Detailed instructions for pairing and installing wireless timers with main controls.

Wireless Repeaters and Wired Timers

Wireless Repeater (Y8252) Installation and Pairing

Guide to installing and pairing wireless repeaters to extend the range of wireless timers.

Wired Fan Timer Installation and Operation

Instructions for installing and operating wired fan timers, including lockout mode.

Timer and Blower Interlocking Installation

Mechanical Timer Installation

Instructions for installing mechanical timers, especially where only two wires are available.

Interlocking ERV/HRV Blower to Air Handler/Furnace Blower

Explains how to interlock the ERV/HRV blower with the HVAC system for synchronized operation.

Dry Contact Control Activation

Adding Dry Contact Controls

Steps for activating dry contact controls for timers and dehumidistats using jumpers.

Unit Wiring Diagrams

Wiring Diagram for Common ERV/HRV Models

Provides a comprehensive wiring diagram for multiple ERV/HRV models.

Unit Wiring Diagram for Specific Model

Wiring Diagram for HRV5-270-TPD-ECM

Detailed wiring diagram specific to the HRV5-270-TPD-ECM model.

Installer Selectable High Speed Settings

Adjusting High Speed Settings

Guide for adjusting DIP switches to select high-speed airflow rates for optimal ventilation.

Control Integration with Circuit Board

Circuit Board Orientation and DIP Functionality

Explains circuit board orientation and the function of DIP switches for ERV/HRV control.

Airflow Balancing Procedures

Pitot Tube Balancing Procedure

Step-by-step guide for balancing airflow using a pitot tube and airflow measuring gauge.

Determining Actual Airflow

Explains how to calculate actual airflow based on gauge readings and duct measurements.

Airflow Balancing Using Pitot Tube

Balancing Dampers

Describes the function and location of balancing dampers within the ductwork collars.

Airflow Balancing Using Door Ports

Door Port Balancing Procedure

Detailed steps for balancing airflow using the unit's door ports and a Magnehelic gauge.

Airflow Balancing Charts - HRV3-150-TPD

Airflow Balancing Charts - HRV3-150-TPD (Continued)

Airflow Balancing Charts - HRV5-150

Airflow Balancing Charts - HRV5-150 (Continued)

Airflow Balancing Charts - HRV5-200-TPD

Airflow Balancing Charts - HRV5-200-TPD (Continued)

Airflow Balancing Charts - HRV5-270-TPD-ECM

Airflow Balancing Charts - HRV5-270-TPD-ECM (Continued)

Airflow Balancing Charts - HRV6-HEX095-TPD

Airflow Balancing Charts - ERV5-150-TPD

Airflow Balancing Charts - ERV5-150-TPD (Continued)

Sequence of Operations and Terminal Block Functions

ERV/HRV Operational Flowchart

Visual flowchart illustrating the sequence of operations for ERV/HRV units.

Terminal Block Operation Details

Explains the function of each terminal on the ERV/HRV unit's terminal block.

Operational Flowcharts: Self-Test and Defrost

Self-Test Operational Flowchart

A flowchart to troubleshoot and verify unit operation through its self-test sequence.

ERV/HRV Defrost Mode Flowchart

Illustrates the logic and conditions for the ERV/HRV unit's defrost mode operation.

Troubleshooting Common Issues

Airflow and Humidity Level Problems

Addresses common issues related to poor airflow, cold supply air, and humidity control problems.

Dehumidistat and Frosting Issues

Guides on troubleshooting dehumidistat operation and frosting in HRV units.

Replacement Parts Identification

Blower Assembly Service Procedures

Blower Assembly Removal and Disassembly

Steps for safely removing and disassembling the blower assembly for servicing.

Homeowner Maintenance Information

Exterior Hoods and Filter Cleaning

Instructions for homeowners to clean exterior hoods and air filters regularly.

Core Cleaning and Cabinet Maintenance

Guidance on cleaning the ERV/HRV core and the inside of the unit's cabinet.

Application Map and Climate Suitability

ERV/HRV Application Map Descriptions

Explains how climate zones influence the choice between HRV and ERV units.

Related product manuals

HEALTHY CLIMATE HRV6-150

60 pages

HEALTHY CLIMATE HRV3-095

42 pages

Healthy Climate Solutions ERV5-150-TPD User Manual

Table of Contents

Questions and Answers:

Healthy Climate Solutions ERV5-150-TPD Specifications

Summary

General Information and Cross-References

Safety and Important Notes

Model and Catalog Number Cross-References

Technical Definitions and Application Guidance

Terms and Definitions

Application Guidance

Required Tools and Materials

Unit Specifications

Unit Specifications (Continued)

Optional Fan Curve Speeds

Unit Dimensions and Diagrams

Ducting, Defrost, and Operational Modes

Ducting for Oval Ports

Defrost Cycle Operation

Ventilation Operational Modes

Ventilation Rate and Control Mode Selection

Determining Ventilation Needs

Operational Modes Overview

iComfort Smart Thermostat Integration

iComfort Control Features

iComfort Installation Overview

ERV/HRV Wiring Diagrams

iComfort Wiring Connections

Thermostat Ventilation Parameter Configuration

Timed Ventilation Control Parameters

ASHRAE Ventilation Control Parameters

Ventilation Control Mode Details

Timed Mode Operation and ASHRAE Standard

Smart Hub Ventilation Parameter Settings

Timed Mode Smart Hub Parameters

ASHRAE Mode Smart Hub Parameters

iComfort User Guide and Dehumidistat Function

Ventilation Home Screen and Settings

Dehumidistat Operation Explained

Ventilation Control Options

Push Button Ventilation Control (Y8249)

Deluxe Ventilation Control (Y8250)

Timer Controls and Their Operation

20/40/60 Minute Timer (Y2169) Operation

Wireless Timer (Y8251) Operation

Wireless Timer Range Extension and Installation Methods Overview

Wireless Repeater (Y8252) Installation and Pairing

Installation Methods Overview

Ductwork Sizing and Installation

Installation Method: Simplified (Return/Return)

Key Points for Simplified Installation

Installation Method: Partially Dedicated

Key Points for Partially Dedicated Installation

Installation Method: Fully Dedicated

Key Points for Fully Dedicated Installation

Unit Installation Location and Mounting

Recommended Installation Location

Suspending the Unit

Specific Model Installation and Drain Connections

Installing the ERV5-130 Mounting Bracket

Installing the Condensate Drain Connection

Installing Optional Plugs (ERV5-150/175-TPD)

Air Distribution Components and Weatherhoods

Installing Grilles and Diffusers

Weatherhood Installation Requirements

Weatherhoods and Dual Hood Kit Details

Fixed Covered Weatherhoods

Dual Hood Kit (Y3813) Installation

Airflow Performance Charts and Control Installation

Intake Airflow Charts

Installing Ventilation Controls

Ventilation Control Installation and Operation

Wireless Timer Pairing and Installation

Wireless Repeaters and Wired Timers

Wireless Repeater (Y8252) Installation and Pairing

Wired Fan Timer Installation and Operation

Timer and Blower Interlocking Installation

Mechanical Timer Installation

Interlocking ERV/HRV Blower to Air Handler/Furnace Blower

Dry Contact Control Activation
