Hearth and Home Technologies GO318-IPI-NG User Manual

Hearth & Home Technologies • Grand Oak Hearth Kits • 4004-323 Rev E . 4/2020
5
Asphyxiation Risk
This appliance produces carbon monoxide
(CO).
• The free opening areas (in square inches)
of the chimney damper as shown in the
following tables must be met.
• User must make sure damper is locked
open.
• The installer is responsible to ensure
proper ventilation of ue gases before
appliance is used.
Fire needs to draft properly for safe
operation.
WARNING
Table 1 for Factory Built Fireplaces
Free Opening Area (in square inches) of Chimney Damper for Venting combustion Products from Decorative Appliances for Installation in
Solid Fuel Burning Fireplaces.
Chimney Ht.
(Feet)*
GO318
LP Gas
GO318
Natural Gas
GO24 & 324
LP Gas
GO24 & 324
Natural Gas
GO30 & 330
LP Gas
GO30 & 330
Natural Gas
10 35.3 not approved 35.3 not approved 44.2 not approved
15 26.4 38.5 26.4 38.5 32.2 45.4
20 22.1 31.2 22.1 31.2 26.4 37.4
25 18.1 27.3 18.1 27.3 22.9 31.2
30 17.3 24.6 17.3 24.6 20.4 28.3
35 15.9 22.1 15.9 22.1 18.9 25.5
40 15.2 20.4 15.2 20.4 18.1 23.8
Table 2 for Masonary Built Fireplaces
Free Opening Area (in square inches) of Chimney Damper for Venting combustion Products from Decorative Appliances for Installation in
Solid Fuel Burning Fireplaces.
Chimney Ht.
(Feet)*
GO318
LP Gas
GO318
Natural Gas
GO24 & 324
LP Gas
GO24 & 324
Natural Gas
GO30 & 330 LP
Gas
GO30 & 330
Natural Gas
6 49.2 64 49.2 64 56.6 71.4
8 59.7 59.7 45.5 59.7 52.4 66.9
10 54.3 54.3 41.7 54.3 48.2 60.2
15 48.8 48.8 37.7 48.8 43.2 54.1
20 44.4 44.4 34.3 44.4 39.8 49.1
30 40.3 40.3 31.2 40.3 35.9 44.5
* Height is measured from the hearth to the top of the chimney.
Minimum height is 6 ft.
G. Negative Pressure
Negative pressure results from the imbalance of air avail-
able for the replace to operate properly. Causes for this
imbalance include:
• Exhaust fans (kitchen, bath, etc.).
• Range hoods.
• Combustion air requirements for furnaces, water heaters
and other combustion appliances.
• Clothes dryers.
• Location of return-air vents to furnace or air
conditioning.
• Imbalances of the HVAC air handling system.
• Upper level air leaks: recessed lighting, attic hatch
opening, duct leaks.
Log Set
Front
Opening
Depth Height
Rear
Width
Natural
BTU
Propane
BTU
GO318 32” 23” 22” 21” 88,000 80,000
GO24
34” 20” 18” 22” 73,000 61,000
GO30
40” 20” 18” 29” 80,000 70,000
GO324
34” 23” 22” 22” 88,000 80,000
GO330
40” 23” 22” 29” 92,000 82,000
Table 3 for Minimum Fireplace Dimensions

Hearth and Home Technologies GO318-IPI-NG Specifications
