Fire Risk
Explosion Risk
Personal Injury Risk
An explosion could occur if a connection is
made directly to an unregulated propane
(LP) tank.
WARNING
Note: Be sure to not cover the pilot assembly (located on
the right side of the burner pan, installed in the vertical
position) with vermiculite.
Fire Risk
Explosion Risk
Personal Injury Risk
Pour vermiculite into each burner pan (LP) to
the point where each pan is completely full.
Failure to do so may cause the lighting to be
delayed and this can be dangerous..
WARNING
Note: For best results, do not pack down the rock wool
except around the carry over tube. The placement of rock
wool can have an eect on ame pattern and may need to
be adjusted to achieve a desired appearance.
Pour vermiculite into each burner pan to the point where
each pan is completely full. Level the vermiculite from right
to left to ensure an even ame pattern. See gure 6.
• Lightly place dime-size pieces of rock wool evenly on top
of the sand and vermiculite completely covering the pan
surfaces. See Figure 7.
Lightly pack dime sized pieces of rock wool around
the vertical part of the carry over tube to aid lighting
the bottom burner pan. See Figure 8a.
Cover the rest of the exposed tube with additional
rock wool pieces. See Figures 8b and 8c.
• Inspect the pilot burner to ensure it is clear of any
rock wool.
• Remove the Platinum Bright Embers™ from the package.
For optimum performance peel each piece apart in layers
and lightly place on top of the vermiculite and rock wool
where the ame is blue. This will achieve the desired
realism.
• The gas burns at the point of the least resistance. In
case of an uneven ame pattern it may be necessary to
adjust the materials in the pans (using an object such as
a screwdriver) to achieve the desired eect. See Figure
9.
• Place desired amount of lava granules on the oor of the
replace. DO NOT ALLOW THE GRANULES TO COME
IN CONTACT WITH THE FLAMES. (Lava granules may
contain moisture which, when heating, may cause it to pop
out during installation and set-up.) Ensure the controls
and switches are unobstructed after the granules are
installed.
• Place logs. See Service Parts.
• Place accent logs around burner on oor of replace.
Fire Risk
Explosion Risk
Personal Injury Risk
Failure to position the parts in accordance
with the diagrams provided with the log
packages or failure to use only parts
approved with this appliance may result in
property damage or personal injury.
WARNING
J. For Propane Gas Installation (for all units).
To Next Page
