IF THERMOSTAT IS NOT SYSTEM POWERED
REPLACE WITH ALKALINE BATTERIES ONCE EVERY YEAR
USE “AA” SIZE
ALKALINE BATTERIES
USE “AA” SIZE
ALKALINE BATTERIES
ELEC
GAS
HP
GAS
Page 15
Step #5 Jumper Configuration
Figure-B)
72
Heat
Off
Cool
Fan On
FanA uto
*Outputs active - For normal operation do not connect to equipment
OUTPUTS
No Demand With Demand
Cooling Mode
Heating Mode
O*
Y, G, O*
B*
W, G, B*
Jumper is used to select Fan On (G)
with Heat (W). Jumper shown in the
factory default position.
