IF THERMOSTAT IS NOT SYSTEM POWERED
REPLACE WITH ALKALINE BATTERIES ONCE EVERY YEAR
USE “AA” SIZE
ALKALINE BATTERIES
USE “AA” SIZE
ALKALINE BATTERIES
ELEC
GAS
HP
GAS
Page 14
Step #5 Jumper Configuration
Figure-A)
Jumper and Jumper are shown in the
factory default positions for typical gas
furnace heating with electric cooling.
72
Heat
Off
Cool
Fan On
FanA uto
*Outputs active - For normal operation do not connect to equipment
OUTPUTS
No Demand With Demand
Cooling Mode
Heating Mode
O*
Y, G, O*
B*
W, B*
