Heat Controller GMUH - Filter Installation Details; Upflow Filter Retaining Rod (Side Return); Downflow Filter Installation

36
F
IGURE 24
U
PFLOW FILTER RETAINING ROD (SIDE RETURN)
F
ILTER
R
OD
4
5-24095-01
F
ILTER ROD
S
UPPORT
A
NGLE
A
E-60520-01
FILTER SUPPORT
ANGLE
(SEE ANGLE DETAIL)
AE-61883-01
FILTER ROD
SUPPORT
ANGLE
AE-60520-01
F
ILTER
S
UPPORT
A
NGLE
A
E-61883-01
CUT-OUT AND DRILL DETAIL
FILTER AND ROD ASSEMBLY
ROD & FILTER SUPPORT ANGLE ASSEMBLY
SOLID BOTTOM MAY BE ORDERED FROM THE FACTORY.
FIGURE 25
DOWNFLOW FILTER INSTALLATION
