Refrigeration
System Installation
Refrigeration System
For Indoor Applications
Installation and
Operation Guide
Table of Contents
1. Ownerʼs Installation Instructions
Performance/Electrical Data
Specifications ............................................................
2
Dimensional Diagrams ..............................................3
Space and Location Requirements
Recommended Unit Placement ................................. 4
Rigging
Mounting .................................................................... 5
Inspection
General Safety Information
Standard Installation Procedure ................................ 6
2. Freezers
Service Information
Maintenance
Sequence of Operation
Freezer System Pre-Setpoints
Electric Defrost Sequence of Operation
Programming Electric Defrost Controls ................7-10
Freezer Defrost Control
Medium and Large Cabinet ....................................... 7
Freezer Defrost Control
Small Cabinet .......................................................... 10
3. Coolers
Defrost Controls
Sequence of Operation
Maintenance ............................................................ 11
4. Service Information
System Troubleshooting Chart ................................ 12
Replacement Parts ..................................................13
5. Wiring Information
Electrical Wiring Diagrams .................................14-19
6. Warranty Information
...................................... 20
Replaces H-IM-81 (1/04)
H-IM-81A October 2004 Part No. 25001801

Table of Contents

Questions and Answers

  • C
    Cheryl RobertsonAug 16, 2025
    Why is my Heatcraft Air Conditioner compressor not running?
    • C
      Chelsea LopezAug 16, 2025
      Several factors can cause a Heatcraft Air Conditioner compressor not to run. It could be due to an open main switch (close the switch), a blown fuse (check for shorts or grounds, investigate overloading, and replace the fuse after correction), tripped thermal overloads (which reset automatically, so monitor the unit when it restarts), a defective contactor or coil (repair or replace it), or the system being shut down by safety devices (determine the cause and correct it before resetting the safety switch). Other potential causes include no cooling being required (wait until cooling is needed), motor electrical issues (check for open windings, short circuits, or burnout), or loose wiring (check and tighten all wire junctions and terminal screws).
  • J
    Jacob WilliamsAug 19, 2025
    What to do if Heatcraft Air Conditioner has high discharge pressure?
    • R
      Richard VillaAug 19, 2025
      If your Heatcraft Air Conditioner has high discharge pressure, it could be due to several reasons. There might be non-condensables in the system (remove them), the fan might not be running (check the electrical circuit and replace the motor if it's defective), the condenser coil could be dirty (clean it), or the system might be overcharged with refrigerant (reclaim refrigerant and recharge the proper amount).
  • B
    Brandon MaysAug 22, 2025
    What causes a Heatcraft Air Conditioner fan not to operate?
    • S
      Shannon JacksonAug 22, 2025
      A Heatcraft Air Conditioner fan might not operate due to an open main switch (close the switch), blown fuses (replace fuses and check for short circuits or overload conditions), a defective motor (replace the motor), a defective defrost control (replace the component), the unit being in a defrost cycle (wait for completion), or the coil not getting cold enough to reset the thermostat (adjust the fan delay setting of the control).
  • J
    Joseph PetersAug 25, 2025
    What to do if my Heatcraft Air Conditioner has low suction pressure?
    • B
      Brian BrownAug 26, 2025
      If you are experiencing low suction pressure in your Heatcraft Air Conditioner, it could be due to a lack of refrigerant (check for leaks, repair, and add charge), a dirty or iced evaporator (clean it), a malfunctioning expansion valve (check and reset for proper superheat), or a condensing temperature that is too low (check ambient temperature, which should be between 50°F and 100°F).
  • N
    Nicholas TorresAug 27, 2025
    Why is my Heatcraft Air Conditioner compressor noisy?
    • S
      Sheila RoweAug 28, 2025
      A noisy or vibrating Heatcraft Air Conditioner compressor can be caused by flooding of refrigerant into the crankcase (check the setting of expansion valves) or a worn compressor (replace it).
  • M
    Morgan ReedAug 30, 2025
    What causes ice accumulating on my Heatcraft Air Conditioner?
    • C
      Cynthia CortezAug 30, 2025
      Ice accumulating on the ceiling around the evaporator and/or on the fan guards of your Heatcraft Air Conditioner can occur if the defrost duration is too long (adjust the defrost termination temperature on the control), the fan delay is not delaying fans after the defrost period (adjust the fan delay setting or replace a bad sensor), there is a defective defrost control or sensor (replace the defective component), or there are too many defrosts (adjust the number of defrosts).
  • H
    Haley JonesSep 2, 2025
    What causes high suction pressure in Heatcraft Air Conditioner?
    • W
      William DavisSep 2, 2025
      High suction pressure in a Heatcraft Air Conditioner can be caused by an excessive load (reduce the load or add additional equipment) or an expansion valve overfeeding (check the remote bulb and regulate superheat).
  • C
    Charles ShepherdSep 4, 2025
    What causes a Heatcraft Air Conditioner compressor thermal protector switch to open?
    • G
      Geoffrey JohnsonSep 4, 2025
      The compressor thermal protector switch in your Heatcraft Air Conditioner might open due to operating beyond design conditions (add equipment to stay within allowable limits), a dirty condenser coil (clean the coil), or an overcharged system (reduce the charge).
  • G
    garysanchezSep 7, 2025
    Why is the room temperature too high with my Heatcraft Air Conditioner?
    • D
      Deborah HernandezSep 7, 2025
      If the room temperature is too high when using your Heatcraft Air Conditioner, it could be because the control cut out is set too high (adjust the control), the superheat is too high (adjust the thermal expansion valve), the system is low on refrigerant (add refrigerant), or the coil is iced-up (manually defrost the coil and check defrost controls for malfunction).
  • D
    Dennis LarsonSep 10, 2025
    What causes coil not clearing of frost during defrost cycle in Heatcraft Air Conditioner?
    • J
      Jessica MoraSep 10, 2025
      A coil not clearing of frost during the defrost cycle in your Heatcraft Air Conditioner may be due to the coil temperature not getting above the freezing point during defrost (check heater operation), not enough defrost cycles per day (adjust the control for more cycles), a defrost cycle that is too short (adjust the defrost control duration setting), a defective defrost control or sensor (replace the component), a defective heater (replace the heater), improper unit installation (check and adjust if necessary), or a plugged drain line (clean the drain line).

Summary

Owners Installation Instructions

Performance and Electrical Data

Details specifications and electrical data for the refrigeration units.

Space and Location Requirements

Outlines critical considerations for unit placement and ambient conditions.

Recommended Unit Placement

Guidance on optimal placement of evaporator sections within the storage space.

Mounting

General Safety Information

Essential safety guidelines for installation and maintenance personnel.

Standard Installation Procedure

Step-by-step instructions for the proper installation of the unit.

Freezers

Freezer Sequence of Operation

Medium and Large Cabinet Freezer Defrost Control

Details the electronic temperature/defrost control for specific freezer models.

Electric Defrost Sequence for Freezers

Programming Electric Defrost Controls

Instructions for setting parameters for the electric defrost control.

Small Cabinet Freezer Defrost Control

Service Information

Troubleshooting

Identifies common problems and their possible causes and corrective steps.

Replacement Parts

Wiring Information

Small Cabinet Cooler Air Defrost Wiring

Small Cabinet Freezer Electric Defrost Wiring

Medium;Large Cabinet Cooler Air Defrost Wiring (Single Phase)

Medium;Large Cabinet Freezer Electric Defrost Wiring (Single Phase)

Large Cabinet Cooler Air Defrost Wiring (Three Phase)

Large Cabinet Freezer Electric Defrost Wiring (Three Phase)
