Heath Zenith - Tune Selection; Select Musical Tune

-3-
598-1127-02
Tune Settings
Your musical Christmas chime has three different selectable tunes. The unit is
factory set to jumper location B. The tune can be changed by moving the tune
setting jumper to a different tune location. The tune setting is located inside
the battery compartment. Only one tune can be selected at a time. The tune
settings are jumper locations A, B, and C as follows:
A: Jingle Bells
B: We Wish You A Merry Christmas
C: Santa Claus Is Coming To Town
1
2
3
Push Button Battery Replacement
Install an alkaline type A23 12 Volt battery. The
positive terminal should be positioned as shown.
* Code Settings 1-3 Must
Match Both Push Button and
Chime
Inside Push
Button
Inside Chime
Tune Setting
Note: Some models might require
the use of tweezers to remove and
replace the jumpers.
A B C 1 2 3
