3.
(_
)
Grasp
the
connector
with
tong-nose
pliers.
Slide
the
nut
into
the
connector
and
turn
the
nut
until
it
is
tight.
Solder
the
resistor
to
the
shield
wires
and
cut off
the
excess
tead
lengths.
\
MATCH
\
rn
YY
Detail
2-11F
Refer
to
Detail
2-11F
and:
1.
(
)}
Slide
the
2-1/2”
length
of
heat
shrinkable
sleeving
up
against
the
nut.
Use
the
heat
from
a
match
to
shrink
the
sleeving.
Turn
the
cable
to
shrink
the
sleeving
evenly.
LARGER
HOLE
=
KNOB
BUSHING
Detai!
2-11G
KNOB
INSTALLATION
Refer
to
Pictorial
2-11
in
the
Illustration
Booklet
for
the
following
steps.
Examine
the
knob
bushings
before
you
perform
the
following
steps.
Notice
that
the
triangular
hole
is
targer
at
one
end
of
the
bushing
than
the
other.
Always
start
at
the
end
of
the
bushing
with
the
larger
hole
onto
the
switch
shaft,
( )
Refer
to
Detait
2-11G
and
push
knob
bushings
onto
the
shafts
of
switches
SW1
and
SW2.
fe)
Yu
vY
3,
(INCHES)
2
3
V8
|
3/8
|
5/8
|
7/8
|
jl
Log
i
i
A
rn
1
(
)
Grasp
the
bushings
just
installed
and
turn
switches
SW1
and
SW2
fully
clockwise.
Refer
to
Detail
2-11H
and
install
a
knob
on
switch
SW1.
Line
up
the
pointer
with
the
1-4S
mark
on
the
front
panel.
(1)
LINE
UP
THE
POINTER
AS
CALLED
OUT
IN
THE
STEP.
PUSH
THE
KNOB
PART
WAY
ONTO
THE
BUSHING,
NUT
DRIVER
iw
KNOB
©
BUSHING
ve
G)
now
CAREFULLY
REMOVE
BOTH
THE
BUSHING
AND
THE
KNOB.
DO
NOT
ALLOW
THE
KNOB
TO
COME
OFF
THE
BUSHING.
PLACE
THE
KNOB
ON
A
TABLE
OR
OTHER
FIRM
SURFACE.
PLACE
A
SOFT
CLOTH
UNDER
THE
KNOB
TO
PREVENT
IT
FROM
BEING
MARRED.
THEN
USE
A
NUTDRIVER
OR
A
LARGE
SCREWDRIVER
AND
DRIVE
THE
BUSHING
INTO
THE
KNOB,
Detail
2-11H
Refer
to
Detail
2-11H
and
install
a
knob
on
switch
SW2.
Line
up
the
pointer
with
the
GND
mark
on
the
front
panel.
Install
a
red
binding
post
cap
on
the
binding
post
at
AC.
Install
a
black
binding
post
cap
on
the
binding
post
at
AD.
Carefully
peel
the
backing
paper
from
the
blue
and
white
identification
label.
Then
press
the
label
onto
the
outside
of
the
rear
panel
as
shown
in
the
inset
drawing,
NOTE:
The
biue
and
white
identification
label
shows
the
model
number
and
production
series
number
of
your
kit.
Refer
to
these
numbers
in
any
communications
with
the
Heath
Company;
this
assures
you
that
you
will
receive
the
most
complete
and
up-to-date
information
in
return.
