24
TEST
AND
CALIBRATION
During
the
preparation
of
the
test
leads
and
cabi-
net,
the
VTVM
has
had
an
opportunity
to
warm
up
thoroughly
and
should
now
be
calibrated,
Turn
the
instrument
off
and
make
sure
that
the
mechanical
zero
position
of
the
meter
pointer
is
correct,
If
not,
adjust
as
before,
(J
Turn
the
instrument
on
again,
ZERO
ADJUST
()
Set
the
Function
switch
to
DC+,
Check
oper-
ation
of
the
ZERO
ADJ
control,
Turning
this
control
should
move
the
meter
pointer
part
way
up
scale,
Set
the
pointer
to
zero
at
the
left
side
of
the
scale
and
check
for
zero
positioning
when
the
Function
switch
is
changed
to
DC-,
It
should
be
possible
to
obtain
a
ZERO
ADJ
control
position
that
will
permit
the
meter
pointer
to
remain
station-
ary
when
switching
through
from
DC+
to
DC-,
If
there
is
an
appreciable
zero
shift
of
more
than
two
divisions
on
the
scale,
it
should
be
regarded
merely
as
an
indi-
cation
that
additional
aging
of
the
12AU7
tube
is
required,
This
aging
canbe
obtained
by
leaving
the
instrument
turned
on
for
a
period
of
46
hours
or
more,
or
through
con-
tinued
use
of
the
VTVM
with
periodic
cali-
bration,
DC
CALIBRATE
(-
)
Insert
the
test
lead
phone
plug,
Set
the
Function
switch
to
DC+,
the
Range
switch
to
1.5
V
and
the
probe
to
DC,
Connect
the
probe
to
lug
1
on
the
rear
wafer
of
the
Range
switch
(the
point
to
which
the
blue
ca-
ble
wire
is
connected
in
Pictorial
4).
(,
)
Adjust
the
DC
Calibrate
control
so
that
the
meter
pointer
falls
directly
over
the
very
small
red
dot
on
the
meter
face,
Approach
the
red
dot
going
up
scale
by
turning
the
screwdriver
control
and
watch
the
meter
read
1,4
volts,
and
1,5
volts,
and
then
the
red
dot,
As
soon
as
the
red
dot
is
reached,
stop
turning
the
DC
Calibrate
control,
Re-
member
that
the
Range
switch
must
be
set
on
1.5
V
for
this
adjustment,
OHMS
CHECK
{
)
Set
the
Function
switch
to
OHMS,
Set
the
OHMS
ADJ
control
for
full
seale
(infinity).
Set
the
probe
switch
to
AC-OHMS
(the
posi-
tion
opposite
the
DC
marking)
and
touchthe
probe
to
the
common
test
clip,
The
meter
pointer
should
drop
to
zero
at
the
left
end
of
scale
(no
resistance),
AC
CALIBRATE
NOTE:
Your
AC
power
line
outlets
may
be
either
2-wire
or
3-wire
types,
Determine
which
type
you
have
and
complete
the
appropriate
AC
Calibration
instructions,
Use
the
AC
Calibrate
With
Line
Cord
Adapter
for
the
2-wire
outlets
and
AC
Calibrate
Without
Line
Cord
Adapter
for
the
3-wire
outlets,
AC
Calibrate
With
Line
Cord
Adapter
CAUTION:
Do
not
allow
the
green
wire
on
the
line
cord
adapter
to
be
grounded
in
any
way.
or
to
touch
any
part
of
the
VTVM.
A
good
way
to
prevent
this
is
to
put
a
piece
of
tape
over
the
spade
lug
on
the
end
of
Lhe
green
wire.
(
)
Install
the
line
cord
adapter
on
the
line
cord,
{
)
Temporarily
remove
the
phone
plug
from
the
jack,
{
)
Set
the
Range
switch
to
1.5
V
andthe
Func-
tion
switch
to
AC,
{
)
Adjust
the
AC
Balance
control
so
no
move-
ment
is
detected
when
switching
from
AC
through
DC-
to
DC+,
{
)
Set
the
Range
switch
to
the
150
V
range
if
you
wired
your
VTVM
for
120
VAC
opera-
tion,
or
to
the
500
V
range
if
you
wired
the
VTVM
for
240
VAC
operation,
Set
the
Function
switch
to
AC,
Set
the
AC
Calibrate
control
fully
clockwise,
Set
the
switch
on
the
test
probe
to
AC,
)
)
)
Reinsert
the
phone
plug,
)
)
Connect
the
test
probe
to
one
side
of
the
AC
line
and
then
the
other
side,
Note
the
lowest
reading
and
remove
the
probe
from
the
AC
line,
