circuit
U101.
U101
is
a
wide-band
amplifier
with
a
gain
of
80.
The
IF
signal,
as
it
is
coupled
from
output
pin
6
of
U101
to
the
input
of
U102,
is
routed
across
a
limiter
network
consisting
mainly
of
diodes
DiGi
and
D102.
This
limiter
circuit
removes
the
peaks
from
the
IF
signal
and
effectively
creates
square
waves
from
it
for
most
input
signal
levels.
The
square-wave
signal
is
routed
into
operational
amplifier
IC
U102
pin
3
which
functions
as
a
waveshaper
and
squeich
circuit.
Positive
feedback
fro
rad
from
C115
causes
the
output
square
wave
from
pin
6
to
switch
up
and
down
very
rapidly.
An
offset
bias
on
the
input
from
the
limiter
diodes
provides
a
squelch
action
for
low-level
signals.
Transistor
Q102
functions
as
a
trigger
circuit.
Positive
current
spikes
are
coupled
into
the
base
of
Q102
through
capacitor
Cii6.
The
collector
output
is
positive-going
trigger
pulses;
which
are
coupled
to
integrated
circuit
U103
through
capacitor
C118
and
resistors
R131
and
R132.
Operational
amplifier
IC
U163
is
a
monostable
multi
normally
low.
When
a
tri
present
on
input
pin
2,
its
is
provided
by
capacitor
C121
resistor
R136.
The
output
pulse
ps
by
set
to
approximately
1.6
trol
R138.
vibrator
whose
output
is
ger
pulse
from
(102
is
tput
rises.
Regeneration
to
input
pin
3
through
oxwsadth
a
aati.
Of
ewiatn
at
U
163
pin
ois
alibration
(CAL)
con-
Tig
ou
mm
al
am
Two
operationa!
amplifier
aww,
WV
104
CELA
WY
Aa,
CLL
low-pass
filters.
The
inputs
to
the
filters
are
pulses
of
fixed
width
and
amplitude
with
spacing
that
varies
according
to
the
deviation
frequency.
AUDIO
CIRCUITS
25C5
The
pulses
are
inte
d
low-pass
filter
network
and,
at
the
out
age
Lo
B.S
=
audio
signals.
A
resistive
volta
ivider
consisting
ist
58,
fo
orm
a
range
di-
6
is
is
a
:
full-
scale
|
7.5
kHz
signal.
At
the
junction
of
resistors
R156
and
R157,
the
signal
is
20
kHz
full-
scale,
and
at
the
junction
of
R157
and
R158,
the
signal
is
75
kHz
full-scale.
The
2
kHz
range
uses
the
same
signal
as
the
7.5
kHz
e,
but
the
gain
of
the
peak
detector
is
changed
by
switching
resistor
R161
into
the
circuit,
along
with
low-pass
filter
resistor
R155
and
capacitor
C138.
a
whose
input
is
a
signal
selected
by
the
range
switch
attenuator
circuit.
The
output
of
U106
is
rectified
by
diode
D107
and
the
signal
is
stored
in
capacitor
C143.
The
direct
current
developed
at
the
output
of
U106
flows
through
the
meter
and
develops
a
negative
feedback
voltage
across
resistor
R167.
Resistor
R161
shunis
resistor
R167
to
reduce
negative
feedback
on
the
2?
kHz
range,
Resistors
R152
and
R153
with
capacitor
C1
form
a
de-emphasis
circuit.
Audio
signals
coming
from
ic
U105
arerouted
into
both
resistors
and
through
one
of
them,
as
determined
by
the
setting
of
De-emphasis
switch
SW1,
and
on
into
capacitor
C1
and
Audio
ral
prawnten
1
GL
contr
UL
R4.
Audio
signals
from
the
center
tap
of
control
R4
are
routed
to
U107
pin
7.
The
amplified
audio
output
signal
is
coupled
from
U107
pin
12
through
capacitor
C149
to
the
primary
winding
of
audio
transformer
T101.
Audio
output
signals
are
coupled
from
the
sec-
ondary
winding
of
T101
to
the
output
Speaker
jack
J4
on
the
Deviation
Meter
front
panel.
Switch
SW2
is
ganged
onto
the
shaft
of
Audio
Level
control
R4.
When
control
R4
is
turned
fully
counterclockwise,
SW2
turns
off
the
power
to
the
audio
amplifier
circuit
to
conserve
battery
energy.
Eel
its
Vase
POWER
SUPPLY
Power
for
the
FM
Deviation
Meter
is
taken
from
ten
Type
AA
(NEDA
Type
15)
batteries
and
(or)
an
op-
tional
Battery
Charger/Eliminator
Accessory.
Zinc-
carbon
or
alkaline
non-rechargeable
cells
with
a
use-
ful
life
of
approximately
80
hours
may
be
used
with-
out
the
Charger/Eliminator
nack
RAE
NSA
U4
Bae
aeeee
at
peu,
nickel-cadmium
batteries
may
be
used
for
a
charged
useful
period
of
approximately
35
hours.
These
bat-
teries
are
opiional
as
the
Deviation
Meier
can
operate
directly
from
the
accessory
power
pack
with
no
bat-
teries
at
all.
The
15-volt
power
source
is
taken
directly
from
the
battery
or
power
pack
through
On-Off
switch
CarTana
mee
bee
At
SW101A
contacts.
Power
for
the
8-volt
supply
also
comes
from
this
source.
or
rechargeable
AUN
sss
BU
