5
This mark is the conrmation that the unit conforms to
the EU guidelines and has been tested according to the
following EU Declaration of Conformity.
Specifications
Environmental Ratings:
Note: for Indoor use
Altitude: up to 2 000m
Temperature: 2°C to 40°C
Maximum Relative Humidity: 80% for temperatures up to 31°C
decreasing linearly to 50% relative humidity at 40°C
Technical Features:
Capacity: (Max. liquid density: 1.2g/cm3 or 1.2g/mL)
Standard round 6-positon tube rotor: 12 mL Max
Strip tube (2x 8-position) rotor: 8 mL Max
Dimensions:
153mm x 128mm x 104mm (LxWxH)
Weight:
1.6 lb (0.73 kg) (Sprout
®
Plus with rotor)
1.9 lb (0.86kg) (Sprout
®
Plus with power adapter)
Maximum Speed & RCF: (with fully loaded rotor)
6,000 rpm Approx., Max RCF: 2,000 x g
Electrical:
Power Adapter rating
Input: 100-240VAC, 50/60Hz, 1.0A
Output: 12VDC, 2.2A
Sprout
®
Plus:
Input: 12VDC
Current (under load): Approx. 0.6A
Power: Approx. 7.3W
Accessories: (All accessories are rated for Maximum speed)
Tube adapters: 6x for 0.2mL tubes and 6x for
0.5mL tubes (120350)
One SnapSpin strip tube rotor (HEA 100012)
(can be used in place of installed round rotor, HEA 100011)
Conforms to:
ANSI/UL Std. 61010-1
IEC/EN 61010-1
IEC/EN 61010-2-020
CAN/CSA C22.2 No. 61010-1.
This product has been tested to the requirements of CAN/CSA C22.2 No.
61010-1 second edition, including Amendment 1, or a later version of the
same standard incorporating the same level of testing requirements.
710213
