Heatmaxx SRCH06D - Assembly Instructions; Step 1: Assemble Base and Legs; Step 2: Install Log Rack

4
2. Place log rack assembly (L) in the center of
unit and attach to legs (J) with M6 x 12 mm
bolts (BB) and washers (CC).
1
2
1.
H
GG
G
J
DD
CC
BB
CC
J
L
AA
Nut x 8
CC
Washer x 8
DD rehsaW gnirpS x 8
GG M6 x 15 mm Bolt x 8
BB M6 x 12 mm Bolt x 4
CC
Washer x 4
AA
Line up the upper stove assembly (G) and
lower stove bowl (H). Position the legs (J)
beneath bowl (H) and attach using
M6 x 15 mm bolts (GG), nuts (AA),
washers (CC) and spring washers (DD).
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
