Heatmaxx SRCH06D - Step 3: Mount Screen Assembly; Step 4: Hang Sliding Door

5
3.
3
E
G
H
CC
AA
DD
EE
Washer x 4
Spring Washer x 4
M6 x 15 mm Flat Bolt
x 4
CC
DD
EE
AA
Nut x 4
4. Hang the sliding door assembly (D) onto support
bar of screen assembly (E).
4
D
E
Support bar
Align the door of screen assembly (E) and gap of
lower stove bowl (H). Attach the smaller end of
screen assembly (E) onto upper stove assembly
(G) with washers (CC), spring washers (DD),
nuts (AA), and M6 x 15 mm flat bolts (EE).
ASSEMBLY INSTRUCTIONS
Hardware Used
