WARNING!B Petrol is highly flammable and explosive, as well as its fumes. You can
be seriously burned or injured while refilling with petrol.
FUELING
WARNING!B Turn off the engine. Never remove the fuel cap or add fuel when
the engine is running or is hot. After stopping the engine, wait until the engine
and the exhaust components cool down completely.
1. Remove the fuel filler cap (fig. 9A).
2. Fill petrol to maximum of one cm below the lower edge of the neck.
3. Don’t overfill! Before starting the engine, wipe the spilled petrol.
4. All closures of the tank and bulk containers needs to be refitted and tightened.
CAUTION!A Never refill the petrol in a room.
• Don’t smoke or use an open flame during refilling.
• Make sure you are away from heat, sparks and flames.
• If petrol is spilled, don’t start the engine. Immediately clean up the spilled petrol. Move the
machine from the area, where the petrol has been spilled and wait until the fuel vapours
dissipate to avoid the possibility of fire.
• Don’t use petrol containing ethanol. Don’t mix oil with petrol. For engine protection, we
recommend using a fuel stabiliser, which is available at filling stations.
• Make sure that water and dirt doesn’t get into the fuel tank.
• Fuel must not be older than 14 days.
Note:I Fuel can damage paint and some types of plastics. When topping up the fuel
tank, be careful and try not spill any petrol. Damages caused by spilling fuel are not
covered by the warranty.
MOTOR OIL
CAUTION!A This engine is delivered without oil, be sure to put oil in the engine
before the starting. Use only below recommended types of oil.
• Use a four-stroke motor oil that meets or exceeds the requirements for performance
class of SF, SG, SH API classification or their equivalent.
• For general use all year round, we recommend SAE 10W-30 HECHT 4T.
• For general use in winter it is recommended to use SAE 5W-40, HECHT 5W-40.
• Choose optimal oil viscosity that match the ambient temperature at which you are
going to operate the machine (fig. 10). DO NOT MIX OILS!
CHECKING THE OIL LEVEL AND ADDING
Note:I Check the oil level only when the engine is off and cool. The machine must
stand level.
1. Remove the oil filler cap / dipstick (fig. 11A) and dry it thoroughly.
2. Pull the plug of the oil filler cap/dipstick fully into the oil filler neck, but screw it. Then
remove it. After pulling out, read the oil level dipstick.
3. If the oil level is near or below the lower limit mark dipstick, remove the oil filler cap / dipstick
and add oil to the engine between the upper and lower mark (fig. 11). Don‘t overfill.
