(fig. 10-11) of snow you wish to throw. Tighten the knobs to secure the deflector. Note: Do not
overtighten the chute deflector knobs.
The discharge chute can be adjusted 190° by rotating. Use the chute handle (fig. 12A) to position
the direction you want to throw the snow (fig. 13).
THE LEFT AND RIGHT CONTROL LEVERS
a) The right hand control lever (fig. 14B) is used to control scooping of snow and its throwing.
Always turn on and off on eliminated surface. Never in the operation. After pressing the lever, the
machine will pick up and throw snow. After releasing the lever machine will stop to sweep and
throw snow.
b) The left hand control lever (fig. 14A) is used to control the drive device. After releasing the
machine will stop. After pressing, the machine starts to move (forward or backward by the
speed that is set by gear lever).
ADJUSTMENT OF COLLECTION DRUM
Height of collection drum can be adjusted in such way that on uneven surface will not be
touched irregularities and that will not be thrown solid objects together with snow, e.g. stones,
pieces of wood etc. Risk of gear and shear bolts (fig. 20A) damage.
1. Loosen nuts of skid shoes on both sides of collection drum (fig. 15).
2. Adjust the height to surface condition. Upper position for uneven surface, lower position for
quite even surface.
3. Before you fasten the nuts check if there is some height difference between lower rail of the
collection drum and skid shoes. Lower rail of collection drum must not be in contact with
bottom. The nut are to be fastened well.
OPERATION
1. Adjust snow throwing chute (direction and distance).
2. Start the engine (let it warm up to operating temperature and adjust the machine to the
outside temperature).
3. Press control levers of auger drive and the auger starts to work.
STARTING THE ENGINE
Always wear gloves, snug winter clothing and sturdy shoes with non slip soles and
protective goggles or a visor during use, maintenance and service.
Before starting release coupling lever (fig. 14B) so that the machine does not start to move
immediately after engine start. Before starting check fuel and oil level. Before removing it is
necessary the engine to be adapted to the outside temperature.
Adjust fuel valve (fig. 16D) to 1.
Move the throttle lever (fig. 16B) to the FAST position (Rabbit symbol).
