ND 280 83
II – 6 Input and Output of Parameter List and Error
Compensation Table
Output format of the error compensation table
First line
Each error compensation table output begins with the start character
< # > (HEX: 0x23).
Second line
Model of position display unit and unit of measure
Third line
Output of axis to be compensated:
The ND outputs a separate error compensation table for each axis to be compensated.
#
<CR> <LF>
1
1 Start character and end of line: 3 characters
N D - 2 8 0 M M <CR> <LF>
234
2 Model of display unit, left-aligned: 13 characters
3 Unit of measure: 6 characters
4 End of line: 2 characters
A X I S X 1 = 0 <CR> <LF>
5678
5 Axis to be compensated, left-aligned: 13 characters
6 Separator block: 3 characters
7 Axis value, right-aligned: 6 characters
8 End of line: 2 characters
