3. REAR GRILL INSTALLATION AND LOCKING
Align the machine head with the rear grill, hang up and then lock it
with plastic nut.
4. BLADE INSTALLATION AND LOCKING
Align the 3 blade with the motor shaft, complete the passing through of them and
then fix the blade with 5 spinner.
Align the convex point with the hole
Tighten the rear grill clockwise
Align the convex with the
blade concave
Lock the blade
counterclockwise
