HELI CPC 25 User Manual

5. Drive Axle
5.1 General Description
2×7.00-12-12PR 4×7.00-12-12PR
2×28×9-15-14PR 2×28×9-15-14PR 2×250-15-16PR 4×28×9-15-14PR
7.00 -WF B-1 5
860k Pa 9 7 0k Pa 970k Pa 930k Pa 9 7 0k Pa
2t、2.5 t
3t
3.5t
7.00 -WF B-1 57.00 -WF B-1 57.00 -WF B-1 5 5.00 S-1 2D5.00 S-1 2D
Type
Front wheel drive type truck, axle body rigidly connected to truck frame, fully floated halfshaft
Truck
capacity
Single wheel type Twin wheel type
Tyre size
Rim size
Tyre pressure
Single wheel type Single wheel type Twin wheel type Single wheel type
(1)Tapered nut
(2) Rim
(3) Stud
(4) Brake drum
(5) Wheel hub
(6) Operation cylinder
(7) Housing
(8) Clip ring for oil seal
(9) Oil seal
(10) Tapered roll bearing
(11) Tapered roll bearing
(12) Nut
(13) Half-shaft
Fig.5-1 Drive axle
-41-
3.8t
3-3. 8t
