21
handle can adjust the steering wheel to the comfortable position that drivers feel.
(2) Steering sensor
The steering sensor transmits steering signal to steering control unit according to
steering wheel rotation angle and steering speed and meanwhile the steering sensor
receives the feedback signal from steering control unit to adjust feedback moment.
(3) Steering transmission mechanism
The steering control unit makes steering motor output corresponding moment and
speed according to signal transmitted by steering sensor. Then the moment and speed are
transmitted to steer wheel through deceleration gear mechanism to make the steer wheel
rotate with a certain angle.
The steering axle of the truck is made up of steering control unit, steering motor,
deceleration gear mechanism, steering wheel axle, steer wheel and so on.
See table 3-1 for tyre and rim model of steering axle.
