Before First Use
Before use, remove all packaging and inspect the appliance for any damage. If there appears to be any
damage, please take the unit back to place of purchase for a replacement.
Assembly Instructions
Base Assembly:
1. Loosen the screw from the adjustable pipe.
2. Put the pipe into the centre hole of the base.
3. Tighten the screw by placing the decorative ring onto the adjustable pipe
and fix it into place.
Motor Assembly:
1. Unscrew the connecting stopper screw of the adjustable pipe.
2. Fix and lock the motor and adjustable pipe by connecting the stopper
screws.
Rear Grill Assembly:
1. Loosen the four screws fixed on the front of the motor housing.
2. Align the four holes of the rear grill to the four holes on the motor
housing.
3. Fix and lock the screws.
Fan Blade Assembly:
1. Place the fan blade into the bottom of the motor axis.
2. Use the screw provided to fix and lock the blade.
Front Grill Assembly:
1. Connect the front grill with the rear grill. The screw hole
must be aligned with the front and rear grill.
2. Fasten the clips.
PLEASE NOTE: Adjustable pole must not be extended past 1.1m high.
