V103/113 Vector User Guide Chapter 2-Installation Page 9 of 35
If you have another accurate source of heading data on your vessel, such as a gyrocompass, you may use its
data to correct for a bias in V103/113 alignment within the V103/113 software configuration. Alternatively, you
can physically adjust the heading of the V103/113 so that it renders the correct heading measurement;
however, adding a software offset is an easier process.
Mounting Options
The V103/113 allows for different mounting options:
Flush mount - The bottom of the V103/113 contains eight M8-1.25 holes for flush mounting the unit to
a flat surface (see Figure 2-6). The eight holes comprise two sets of four holes. The inner four holes
are in the same location as the V102, allowing you to use the V103/113 as a drop-in replacement. The
outer four holes provide a wider mounting option.
Pole mount - The bottom of the V103/113 contains a mounting hole (1" thread, 0.9" depth) for easy
pole mounting. Hand tighten until snug (do not overtighten). The set screws on the long sides of the
base (see middle drawing in Figure 2-6) allow you to secure the V103/113 in place (3/16" Allen wrench
not included).
Bracket mount - You can purchase on optional mounting bracket. See Table 1-1 for bracket part
information.
