V103/113 Vector User Guide Appendix B -Technical Specifications
Page B3
Table B-2: Beacon Sensor Specifications (V113 only) (continued)
Item Specification
Operating modes Manual, automatic, and database
Compliance IEC 61108-4 beacon standard
Table B-3: Communication Specifications
Item Specification
Serial ports RS-232 (full-duplex)
RS-422 (1 full duplex, 1 half duplex)
Baud rates 4800, 9600, 19200, 115200
Correction I/O protocol
RTCM SC-104, L-Dif™
5
Data I/O protocol NMEA 0183, NMEA 2000, Crescent binary
5
, L-Dif
Table B-4: Power Specifications
Item Specification
Input voltage 6 to 36 VDC
Power consumption V103 V113
~ 4.3 W nominal ~ 4.6 W nominal
Current consumption V103 V113
~ 0.36 A nominal ~ 0.38 A nominal
(GPS L1 + GLONASS L1)
(GPS L1 +GLONASS L1 +
Beacon)
Power isolation Isolated to enclosure
Reverse polarity protection Yes
Table B-5: Mechanical Specifications
Item Specification
Enclosure
UV resistant, white plastic, AES HW 600G, non-
corrosive, self-extinguishing
Dimensions 66.3 L x 20.9 W x 14.6 H (cm)
26.1 L x 8.3 W x 5.8 H (in)
Weight V103 V113
2.1 kg (4.6 lb) 2.4 kg (5.4 lb)
Power/data connector 18-pin, environmentally sealed
Table B-6: Environmental Specifications
Item Specification
Operating temperature -30°C to +70°C (-22°F to +158°F)
Storage temperature
-40°C to +85°C (-40°F to +185°F)
Humidity 95% non-condensing
