Hendi 271575 - General information; Rating; Main Unit Construction

5
EN
2) Rating
General information
1) Main Unit Construction
1. Top cover
2. Door
3. Ice-making & water tank assembly
4. Front panel
5. Operation panel
6. Air outlet: Must keep the air circulate smoothly,
hot air will blow out when unit running.
7. Water draining port.
8. Water inlet port for water supply.
Accessory: White 2 meters long water drain pipe,
connector for the water faucet, white 3 meter long
water supply pipe(ø 6.35mm).
POWER CONSUMPTION 300W
IP RATING IPX1
CLIMATE CLASS SN, N, ST, T
POWER SUPPLY VOLTAGE 220-240V~ / 50Hz
ICE MAKING CAPACITY (KG/24H) 35kg/24Hour *
REFRIGERANT CHARGE R134A, 245g
UNIT DIMENSIONS(W X D X H) (mm) 448 x 400 x 798
NET WEIGHT/GROSS WEIGHT(KG) 28.3Kg
WATER CONSUMPTION(L/24H) 50L
MAX ICE STORAGE CAPACITY(KG) 15Kg
RUNNING CONDITIONS ROOM TEMP 10-38ºC
WATER SUPPLY TEMP 5-35ºC
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 21ºC ROOM TEMPERATURE AND 10ºC WATER TEMPERATURE.
