19
Use a 3/16-inch or 5 mm hex key
to turn the Manual Override gear
counterclockwise. To prevent
damage to the Horizontal
Dock, use extreme caution not
to over-rotate the emergency
override gear past the point
where the MacBook can be
removed. The override gear will
click if turned in the incorrect
direction (clockwise) to protect
the Horizontal Dock.
Horizontal Dock Power
Supply Specications
Frequency:
50 to 60 Hz, single phase
Line Voltage:
100 to 240 V
Output Voltage:
19 V DC, 8.0 A
Operating Environment
For optimal performance,
operate your dock within the
following ranges:
Operating Temperature:
55° to 95°F (13° to 35°C)
Storage Temperature:
-4° to 113°F (-20° to 45°C)
