1 Hammer Rod Protector 1
2 Chuck 1
3 Ø28 Steel Wire Block Ring 1
4 Support Washer 1
5 Rubber Ring 1
6 Lock Bead Sheath A 1
7 Insert Block 2
8 Spring Rack 1
9 Flex Sheath Spring 1
10 Ø30 Retaining Ring 1
11 Lock Bead Sheath B 1
12 Fluorine O-Ring Ø38×Ø2.5 1
13 Hammer Staff Sheath 1
14 Cylinder Lock Bead Ø9×14 6
15 Fluorine O-Ring Ø33×Ø2 1
16 Impact Hammer Assembly 1
20 Ø62 Retaining Ring 1
21 Oil Seal Ring Ø42×Ø58×8 1
22 Lubricated Bearing A 1
23 O-Ring Ø48.5×Ø7 1
24 Isolation Pad 1
25 Ø42 Stop Ring 2
26 Antifriction Ring 1
27 Locating Sleeve 1
28 Cylinder 1
29 Inner Sliding Block 1
30 Fixed Distance Sleeve 1
31 Block Lock Bead Ø8.5×Ø10×17.9 4
32 Clamp 1
33 Shock Absorption Ring 1
34 Sliding Sleeve 1
35 Sliding Sleeve Spring 1
36 Limit Ring 1
37 Impact Piston 1
38 Fluorine O-Ring Ø30.5×Ø3.5 2
39 Cover 1
40 Hex Socket Bolt M4×12(12.9) 2
41 O-Ring Ø62×Ø2 1
42 Ø62 Stop Ring 1
43 Crank Housing 1
44 Lubricated Bearing B 1
45 Drive Sleeve 1
46 Clutch 1
48 Antifriction Pad B Ø41×Ø47.5×0.3 1
49 Big Cone-Shaped Gear 1
50 Piston & Connecting Asm. 1
56 Small Cone-Shaped Gear Asm. 1
63 Needle Bearing 14×22×26.5 1
64 Limit Shims Ø15×Ø22×1 1
65 Mode Selector 1
66 Wool Column 1
67 O-Ring Ø16x Ø3 1
68 Dial Staff Sheath 1
69 Ø7 Steel Ball 2
70 Dial Staff Sheath Spring 1
71 St5.5×85 Screw 4
72 Gear Cover 1
73 Hex Socket Bolt M5×20(12.9) 4
74 Airproof Ring 1
75 Selector Fork 1
]3:9 2$DS:E79E"C m96
76 Torsion Spring 1
77 Lifting Jack 1
78 Eccentric Gear Asm. 1
87 Needle Bearing Ø12×Ø19×12 1
88 Screw Bracket 2
89 Needle Bearing Ø20×Ø28×13 1
90 Seal Ring Asm. 1
91 Armature 110-120v 1
95 Dust Cap 1
96 Fan Guide 1
97 Stator 110-120v 1
98 Screw St4.8×70 2
99 Housing 1
100 Terminal 5
101 Carbon Brush 2
102 Carbon Brush Wire 2
103 Coil Spring 2
104 Machine Screw St3.5×16 4
105 Ball Bearing 628LHV CW 1
106 Bearing Ring 1
107 Nut M8x1x3.8 1
108 Fan Cover 1
109 St4.8×20 Screw 8
110 Switch Box 1
111 Internal Switch 1
112 Hex Socket Bolt M5×12 (12.9) 2
113 Switch Box Cover 1
114 Screw St4.2×16 6
115 Switch 1
116 Switch 2 Cover 1
117 Speed Adjuster 110-120v 1
118 Indicator 1
119 Machine Screw St5.5×25 2
120 Ø6 Flat Washer (Ø6.4×Ø18×1.6) 2
121 Side Handle Asm. Base 1
122 Top Shock Absorption Jacket 1
123 St4.8×40 Screw 2
124 Bottom Shock Absorption Jacket 1
125 Split Pin Ø2×14 1
126 Shaft Pin Ø6×55 1
127 Shock Absorption Spring 1
128 Main Handle 1
129 Trigger 1
130 Switch 3 110-120v 1
131 Cord Clip 1
132 Cord Armor 1
133 Cord 1
134 Main Handle Cover 1
135 Side Handle Asm. Steel Tie 1
136 Spring Column Pin Ø5×23 1
137 Ring Bolt 1
138 Side Handle Asm. Base 1
139 Side Handle Cover 1
140 Side Handle 1
142 Grease Tube 1
143 Ø31 Retaining Ring 1
801 Lubricated Bearing A Asm. 1
802 Crank Housing Asm. 1
803 Gear Cover Asm. 1
