hergom E-20 N - 2.8-LIST OF SPARE PARTS

44
2.8 – LIST OF SPARE PARTS
Due to the structural similarity of the two stoves, the list of spare part for both is detailed,
based on the overview of the E-20 N stove, shown on the previous page.
POS.
CODE
NAME
E-20 N
E-21 N
1
HF03086
HF03086
SURFACE
2
CL03048
CL03048
ROOF PROTECTOR
3
T5460
T5460
STOVE SECURING BAR
4
HL771
HL771
BAFFLE (FIRE GUARD)
5
X-418P
X-418P
SECONDARY AIR COLLECTOR
6
J0107
J0107
BRICKS 220 X 109 X 20 E20/21
7
CP520
CP520
BRICK SUPPORT
8
HP00196
HP00196
HEARTH GRILLE LID
9
HP685
HP685
REAR (GRILLE)
10
HF00683
HF00683
LEFT / RIGHT SIDE
11
X-647P
X-647P
PRIMARY AIR BRIDGE
12
HP00687
HP00687
PRIMARY AIR VALVE
13
Q2027
Q2027
AIR VALVE CONTROL
14
HF00682
HF00682
FRONT
15
CL00680
CL00680
HEARTH DOOR LOCK
16
Q0326
Q0326
DOOR HINGE
17
CL290
CL290
GLASS RETENTION CLIP
18
Q00140
Q00140
SPRING LOCK WASHER
19
CPQ00273
CPQ00273
GREY HEATER / ASH PAN DOOR HANDLE FOR PAINTED
HEATERS
19
CPQ002730
CPQ002730
BLACK HEATER / ASH PAN DOOR HANDLE FOR
ENAMELLED HEATERS
20
Q002750
Q002750
HEARTH DOOR GLASS / ROOF
21
HF03005
HF03006
HEARTH DOOR
22
T316
T316
DOOR CRANK
24
HP03087
HP03087
VAPOUR EXTRACTION COLLAR
25
HP03085
HP03085
REAR
26
J0112
J0112
BRICK BAFFLE 210 X 110 X 20 E-20/21
27
HP773
HP773
BRICK BAFFLE SUPPORT
28
CP160
CP160
ASH PAN
29
HP00681
HP00681
BASE
30
CP664
CP664
PRIMARY AIR REGULATION LEVER
31
HF03004
HF03004
ASH PAN DOOR
32
HF03078
HF03078
FLUE COVER
33
CL03039
CL03039
FLUE COVER PROTECTION PLATE
INDUSTRIAS HERGÓM, S.A. may not be held liable for incorrect installation or use. They
reserve the right to modify their products without notice.
Liability for any faults in the manufacture shall be subject to the criteria and verification of
their technicians, which, in every case, shall be limited to repairs or replacement of parts and
shall not include work and any damages which may be incurred due to these said repairs.
