HERO HF 100 - Vehicle Views

(3) Turn signal lamp switch
(5) Rear view mirror
(6) Headlamp dimmer switch
(8) Speedometer
(1) Turn signal indicator
(4) Clutch lever
(7) Odometer
(9) Neutral indicator
(2) Horn switch
(11) Fuel gauge
(16) Fuel tank cap
(12) High beam indicator
(10) Programmed FI malfunction indicator
lamp (MIL)
(13) Front brake lever
(14) Throttle grip
(15) Ignition switch with steering lock
TOP VIEW
2
4
5
11
14
13
2
VEHICLE VIEWS
3
6
1
7
9
10 12
15
*Accessories and features shown may not be part of standard fitment.
