HEROSE 06001 - Description of the Safety Valve

Operating instructions
4
Phone +49 4531 509-0
3.2 Transportation
 Transport the safety valve in the packaging supplied.
The safety valve is delivered in a ready-to-operate state with the connections protected by caps.
 Protect the safety valve against shocks, impacts, vibrations and dirt.
 Adhere to a transport temperature range of -20 °C to +65 °C.
3.3 Storage
 Store the safety valve in a clean and dry place.
 Make use of a desiccant or heating in damp storerooms to prevent the formation of
condensation.
 Adhere to a storage temperature range of -20 °C to +65 °C.
4 Description of the safety valve
Refer to the respective catalogue page for further detailed information.
4.1 Structure
Design
Directly acting angle safety valve, spring-loaded.
4.2 Marking
The safety valves are provided with an individual marking for identification.
Symbol
Explanation
e.g. G1/2
Connection size
PN…..
Rated working pressure (max. permissible operating pressure)
Manufacturer's mark "HEROSE"
e.g. 1.4301
Material no.
0045
CE-mark, ID of notified body
e.g. 06381
Type
01.18
Date of manufacture MM/YY
O2
For use with oxygen
TÜV SV XX – XXX
Component identification
e.g. EN13648-1:xxxx
Applied standard; issue date
-…..°C +…..°C
min / max temperature
UV stamp holder, National Board Registered
10% / 5%
Normal stroke / full stroke
e.g. 1.8 mm
Stroke
Axx.x
xx.x
Narrowest flow cross-section A in mm²
narrowest flow diameter d
0
before the valve seat in mm
S/G/L
F/K/S
Intended for vapours, gases, liquids
Intended for free-flowing, grainy, dusty goods
0.xx
Permitted coefficient of discharge 
w
e.g. x.xxbar
Setting pressure
xxx Nm³/h
Volumetric flow rate
xxx kg/h
Mass flow rate
e.g. 01234567
Serial no.
CRN XXXXXX.XX
Canada approval no.
TSF700D36-2021
Manufacturing permit for special devices – People's Republic of China
0045 beP
PI marking, number of notified body, in-house testing service
