Hertz HT 20 - Flush Mounting; Posizione E Angolazione; Size; Suggested Positioning; Angle

TWEETER TWEETER
Ingombro / Size
Posizione e angolazione / Suggested positioning / angle
Montaggio incassato / Flush mounting
A
B
D
C
Manuale d’uso | Owner’s manual
Trim Ring
Trim Ring
38 35 14 22
A B C D
1”
1/2
1”
3/8
9/16” 7/8”
44 41 15 26
1”
3/4
1”
5/8
5/8” 1”
1/16
HT 20
HT 25
48 45 19 29
1”
15/16
1”
13/16
3/4” 1”
3/16
Misure espresse in mm e pollici / Measures in mm and inches
HT 28
HT 20:
36 mm
1”
7/16
HT 25:
42 mm
1”
11/16
HT 28:
46 mm
1”
13/16
HT 20:
36 mm
1”
7/16
HT 25:
42 mm
1”
11/16
HT 28:
46 mm
1”
13/16
6 7
