Technical data
Housing:
Polycarbonate
Device designation
Housing dimensions:
Compact housing
231 × 125 × 90 mm
Modular
(panel mounting)
200 × 122 × 30 mm
Modular
(control unit)
192 × 128 × 63 mm
Connection set for
the compact housing
3 × M32×1.5 with multiple sealing insert for 6 cables
3 × M16×1.5 for supply and communication
Electrical
connections:
Cross-section rigid/flex:max. 2.5 mm², flex.: max. 2.5 mm
2
without ferrule
Rest: cross-section rigid: max. 1.5 mm
2,
flex.: max. 0.75
mm
2
with ferrule
Mounting:
Compact housing
Wall mounting. Mounting position: vertical
Modular
Panel-mounting housing, vertical mounting position
Control unit: standard rail
Ambient conditions
Climate
Storage
- 20°C…+ 70°C
Transport
- 25°C…+ 85°C
Operation
Compact housing
-20°C…+50°C
in EX zone 22: -20°…+40°C
Modular
-20°C…+50°C
-No EX approval
Relative humidity
Relative humidity 95%, no condensation allowed,
KUF according to DIN 40400
