HE 5731 Operating instructions
42
# 373344, Version 1.5
Options
1. Open the housing cover (see Figure 12).
2. Put the terminal extender with the pin header onto the terminals 17-19.
3. Connect the external device (see Figure 25).
4. Close the housing cover.
Terminal extender current input / output (article number # 57310089)
Note!
If no external device is connected, the analogue output must be bridged.
