HEX Alton - Page 36

Assembly Guide
34
ASSEMBLY STAGE 29
LOCATE AND SECURE DOOR STRIP 0205-74.
29B
29B
0205-74
29A
SECURE DOOR STRIP ONTO FLOOR PANELS AT x2 LOCATIONS
INDICATED, USE EXISTING HOLE AS A LOCATION GUIDE.
LOCATE DOOR STRIP 0205-74 AS SHOWN.
IMPORTANT: ENSURE DOOR STRIP IS PUSHED AGAINST DOOR POST RETURN.
FK7
FK1
29A 29B
