Assembly Guide
39
ASSEMBLY STAGE 34
LOCATE AND SECURE ROOF CHANNEL ASSEMBLY 0256-03.
x2
34A
34A
34B
34B
34A
34A
0256-03 0256-03
34B
34B
FK1
FK1
0252-11
FK5
0252-12
SECURE ROOF CHANNEL ASSEMBLY TO SHORT ROOF SUPPORT 0252-11
FIXING POINT (x2 EACH SIDE) USING FASTENERS DETAILED ABOVE.
34B
SLOT EACH ROOF CHANNEL ASSEMBLY 0252-12 INTO ROOF SUPPORT.
FIXING POINT (x3 EACH SIDE) USING FASTENERS DETAILED ABOVE.
FK5
FK5
FK1
34A
0252-11
0252-12
