HF Scientific CLX-Ex User Manual

CLX-Ex (10/11) Page 4
REV 1.5
VORTEX ASSEMBLY
PURGE
CONTROL
INLET WATER STRAINER
BUFFER REAGENT
BOTTLE
PUMP SOLENOID
OPTICAL BLOCK ASSY
MAIN CONTROL
CHASSIS
TEMPERATURE CONTROL
(UNDER FINGER GUARD)
WIRING COVER
REPLACEMENT
REAGENT CONTAINER
GROUND LUG
WATER REGULATOR
DRAIN
AIR INLET & WATER INLET
WATER INLET
AIR INLET
POWER INLET
I/O SIGNALS
VENT ASSEMBLY
1.4 Orientation
From the diagram below the major components can be located. Note that two reagents are
required the buffer and the indicator. The reagents are discussed in the Routine Maintenance
section 10.0.
Figure 3: The CLX-Ex with Cover Open
