Stop Bit
1,2
Check Bit
None,Even,Odd
Baud Rate
TTL：1200 bps~460800 bps
Flow Control
No Flow Control
Half-Duplex(RS485)
Software Flow Contorl
Software
Configuration
Serial AT Command
IOTService Serial Port Configuration Software
IOTService Network Configuration Software
Firmware Upgrade
UART or OTA Upgrade
Basic Parameter
SIM Card
Nano SIM card(1.8V/3V)
Size
68.5mm x 35mm x 17.8mm
Operating Temp.
-40 ~ 85°C
Storage Temp.
-45 ~ 105°C, 5 ~ 95% RH（no condensation）
Input Voltage
Elfin-EG41: 9~18VDC@1A
Elfin-EG41A: 9~36VDC@1A
Average Working
Current
~300mA@9V
Peak Current
2A
1.3. Key Applications
The Elfin-EG41 module connects the serial device to the Internet and conforms to the TCP/IP
protocol for transmitting serial data.
⚫ Remote device monitoring
⚫ Production asset tracking and monitoring
⚫ Security field
⚫ Industrial sensors and controllers
⚫ Health medical equipment
⚫ ATM equipment
⚫ Data acquisition equipment
⚫ UPS power management equipment
⚫ Telecommunication equipment
⚫ Data display device
⚫ Hand-held device
⚫ Attendance system and terminal equipment
