Line level signals can be connected to the input using a balanced or unbalanced XLR or a 6.3mm jack.
The input signal can be supplied to another device through a Male XLR in the Link Output socket.
Passive (8 ) extension monitors can be connected via Ω Speakon™ from the Extension Speaker socket.
VECTOR ACTIVE SERIES SETUP DIAGRAM
VECTOR ACTIVE SERIES SETUP DIAGRAM
Link
Monitor/Aux Out
Active Monitor Active Monitor
Passive 8Ω Monitor
Extension Speaker
