4.Theportisintroduced
4.1 “HDMotor”：ConnectstotheHeadmotor,andlifts/lowersheadsection.
4.2 “FTMotor”：ConnectstotheFootmotor,andlifts/lowersfootsection.
4.3 “TiltMotor”：ConnectstotheTiltmotor,andadjuststilt.
4.4 “Power”：Connectstothepower
supplybox,controlspowe rsupply.
4.5 “USB”：ConnectstotheUSBadapterbox,andUSBadapterboxandUSBsocketconnection.
4.6 “LED”：Connectswithlights.
4.7 “SYN”：Samesteps.Connectanothercontrolbox,andtwocontrolboxeswillsynchronize
4.8“HDMassage”：ConnectstoHeadmassage
motor,controlsstrengthofheadmassageand
on/off.
4.9 “FT Massage”： Connects to Foot massagemotor, controlsstrength of foot massage and
HeadMotorPort
FootMotorPort
PowerInputconnection
USB
Connection
LED
Connection
SYNCCord
Connection
FootMassage
MotorPort
HeadMassage
MotorPort
TiltMotorPort
