Hi-Force HP110 - Declaration of Incorporation; Conformity

Operating Instruction Manual:
OM-HP-STEEL-01
Serial Numbers:
From: DF6685
6
3.0 Declaration of Incorporation/Conformity
Hi-Force declares that this product has been tested and complies with the standards and
declarations as set out in the Declaration of Incorporation/Conformity (DoI/DoC). The DoI/DoC is
included as Annex A to this instruction document and is supplied with all shipments of this
product.
4.0 Oil Specification
Hi-Force tools will use 1 of 2 grades of oil, dependant on the tool. The tools are designed to operate at
temperatures between -20°C and 80°C. Details of the oil used in this product can be found in, Section 6.2
ISO Hydraulic Oil Grade
Temperature Range: Degrees Celcius (°C)
From:
To:
ISO15
-23
44
ISO46
-2
73
4.1 HP-Steel Specifications
Refer to the nameplate on the pump for identification.
Model
Number
Valve
Type
Displacement per
stroke (cm3)
Usable
Oil
Capacity
(litres)
Handle
Effort
(kg)
Weight
(kg)
1
st
stage
2
nd
stage
Single stage pumps for single acting cylinders and tools.
HP110
2-way
2.9
-
1.0
45
5.6
Two stage pumps for single acting cylinders and tools.
HP227
2-way
12.9
2.3
2.3
38
10.5
HP257
2-way
12.9
2.3
4.1
38
15.2
HP227FP*
2-way
12.9
2.3
2.3
38
10.5
HP227FPC**
2-way
12.9
2.3
4.1
38
15.2
*HP227FP comes with a foot operated handle.
**HP227FPC Comes with a foot operated handle, pressure gauge, gauge mounting block and 3 meter
hoses with male coupler.
