Hi-Force HP110 - Component Identification

Operating Instruction Manual:
OM-HP-STEEL-01
Serial Numbers:
From: DF6685
7
5.0 Component Identification
1
Oil Reservoir
5
Filler Cap (dipstick attached)
2
Handle
6
Outlet Port 3/8 NPT
3
Transit plug
7
Release Valve
4
Breather
8
Identification plate
5
Figure 5.1: Component Identification (HP110 Model shown)
2
7
4
5
3
1
6
8
