Hi-Link HLK-LD2410B User Manual

Shenzhen Hi-Link Electronics Co.,Ltd
User manual
HLK-LD2410B
Page 14 /18
7. Performance and electrical parameters
Operating frequency
24GHz~ 24.25GHz
Compliant with FCC, CE, non-commission certification standards
Operating Voltage
DC 5V, power supply capacity>200mA
Average operating current
79 mA
Modulation
FMCW
Interface
A GPIO, IO level 3.3V
A UART
Target application
Human presence sensor
Detection distance
0.75m ~ 6m, adjustable
Detection angle
±60 °
Distance resolution
0.75m
Sweep Bandwidth
250MHz
Compliant with FCC, CE, non-commission certification standards
Ambient temperature
-40 ~ 85℃
Dimensions
7mm x 35 mm
Table 2 Performance and electrical parameters table
Figure 11 Measured data of module working current
